Table
|
Spindle nose – table (mm) |
102 - 610 |
|
Table working surface W x D (mm) |
1.321 x 508 |
|
T-Slots (DIN 650) |
5 x 18 x 100 |
|
Load max. (uniform distribution) (kg) |
1800 |
Travels
|
X-Axis (mm) |
1.270 |
|
Y-Axis (mm) |
508 |
|
Z-Axis (mm) |
508 |
Spindle
|
Spindle Taper (DIN 69871 A) |
SK40 |
|
Spindle Speed max. (rpm) |
10.000 |
|
Spindle Power (kW) |
15 |
|
Spindle Torque max. (Nm) |
99 |
Feedrates
|
Rapid traverse X-Axis / Y-Axis / Z-Axis (m/min) |
28 / 28 / 28 |
Automatic Tool Changer
|
Number of stations |
24 |
|
Tool diameter max. (mm) |
80 |
|
Tool length max. (mm) |
250 |
|
Tool weight max. (kg) |
7 |
Further details
|
Floor space required (mm) (doors open, incl. control and chip conveyor) |
4.086 x 3.312 x 2.543 |
|
Machine weight (kg) |
4.250 |
|
Content coolant tank (l) |
122 |
|
Chip auger |
Optional |
Information may change without notice. Optimum machine performance is reliant upon installation conditions at the facility, such as power supply, air supply, and ambient air conditions.
